Product Name
CUBI II
Material
Steel
Dimensions
431x277x431mm (LxWxH)
Drive Bays
HDD Cage: 3.5″ x2 & 2.5″ x3
Expansion Slots
7 Standard Slots, Support VGA Card Vertical Installation
Motherboard Support
E-ATX
ATX (Support Back Plug)
Micro ATX (Support Back Plug)
Mini ITX
Power Supply
Standard PS2 ATX PSU
Fan Support
Top: 120mm x3 or 140mmx2
MB Panel: 120mm x3
Bottom: 120mm x3 or 140mmx2
Rear: 120mm x1
Radiator Support
Top: 280/360
MB Panel: 360
Bottom: 360 (M-ATX MB Only)
I/O Panel
USB 3.0 x2
USB-C x1
HD Audio
CPU Cooler Clearance
165mm
VGA Length Limitation
370mm
PSU Length Limitation
200mm
