Feature Details Chipset / Socket AMD B650 / AM5 — supports Ryzen 7000 / 8000 / 9000 series CPUs Form Factor ATX (305 × 244 mm) Memory Support 4× DDR5 DIMM slots, up to 192 GB, supports DDR5 up to 7200+ MHz (OC) with AMD EXPO Power Delivery 12+2+1 digital phases (Core/SOC/MISC) with MSI Core Boost design Expansion / PCIe Slots 2× PCIe 4.0 ×16 (CPU-driven x16/x4), 1× PCIe 4.0 ×16 (×4 lanes from chipset), 1× PCIe 3.0 ×1 slot Storage 2× M.2 PCIe 4.0 x4 slots, 4× SATA 6 Gb/s ports; RAID 0/1 support for SATA and M.2 Networking Realtek 8125BG 2.5 Gb Ethernet; onboard Wi‑Fi 6E & Bluetooth 5.3 module in M.2 Key‑E slot USB Connectivity Rear: USB 3.2 Gen2×2 (Type‑C, 20 Gbps), 3× USB 3.2 Gen2, 4× USB 3.2 Gen1; internal headers for USB 3.2/USB 2.0, and front Type‑C Video Outputs HDMI 2.1, DisplayPort 1.4 (requires compatible CPU iGPU) Audio Realtek ALC897 7.1-channel HD Audio codec, shielded design Cooling & Design Features Extended heatsink, M.2 Shield Frozr, FROZR AI Cooling, EZ Debug LEDs, Flash BIOS button, 6‑layer PCB with thick copper Software & Utilities MSI FROZR AI cooling tech, Armory CRATE utilities, BIOS Flashback, Core Boost power tuning Warranty 3 years (region dependent)
Feature Details Model ASUS TUF Gaming B650‑Plus (pangoly.com) Chipset / Socket AMD B650 / AM5 – supports Ryzen 7000 / 8000 / 9000 series CPUs Form Factor ATX (305 × 244 mm) Memory Support 4× DDR5 DIMMs, up to 128 GB; supports DDR5‑7600+ OC via EXPO profiles VRM / Power Design 12+2 power stages (~60 A each) with durable TUF components Expansion Slots 1× PCIe 4.0 ×16 (reinforced), 1× PCIe 4.0 ×16 (×4), 2× PCIe 4.0 ×1 Storage Options 3× M.2 (1× PCIe 5.0 ×4, 2× PCIe 4.0 ×4), 4× SATA 6 Gb/s Networking Realtek 2.5 Gb Ethernet with TUF LANGuard USB Connectivity Rear I/O: 1× USB 3.2 Gen 2×2 Type‑C, 3× USB 3.2 Gen 2, 4× USB 2.0 Video Outputs HDMI 2.1 and DisplayPort 1.4 (if using Ryzen with integrated graphics) Audio Codec Realtek ALC S1200A 7.1-channel HD Audio with shielding and premium capacitors Other Features Aura Sync RGB header, BIOS FlashBack button, M.2 heatsinks, Pre-installed I/O shield Software & Utilities Armoury Crate, Fan Xpert 2+, Q-Latch M.2, Q-LED debug lights Warranty 3 years (region-dependent)
Feature Details Chipset / Socket AMD X670 / AM5 (Wise-Tech) CPU Support AMD Ryzen 7000 / 8000 Series (Midas Computer Center, Wise-Tech) Power Delivery Twin 16 + 2 + 2 digital VRM phases (Midas Computer Center, EliteHubs) Memory DDR5 up to 8000 MHz (OC), dual-channel, 4 DIMM slots, up to 128 GB / 192 GB (varies) Storage 1× PCIe 5.0 ×4 M.2, 3× PCIe 4.0 ×4 M.2, 4× SATA III Graphics / PCIe 1× PCIe 4.0 ×16 (×16), plus additional PCIe x16 slots (×4 / ×2 lanes) Networking Wi‑Fi 6E (AMD RZ616 / MT7922A22M), Bluetooth 5.2, up to ~2.4 Gbps; Realtek 2.5 GbE LAN USB Connectivity Back: USB 3.2 Gen1 ×6, USB 3.2 Gen2 ×2, USB‑C Gen2×2 ×1; Internal headers include USB‑C Gen2×2 and USB Gen1/2.0 Audio Realtek HD Audio codec, 7.1‑channel support Cooling & Thermal Mega‑heatpipe VRM heatsinks, M.2 Thermal Guard, Smart Fan 6 with hybrid fan headers & fan stop feature BIOS Features Q‑Flash Plus (BIOS update without CPU/DRAM/GPU), EZ‑Latch slots & M.2, Smart Backup support Extras HDMI 2.1 port, Q‑Flash Plus button, bundled Norton Internet Security, TPM header, ECC unsupported Form Factor ATX (305 × 244 mm) Warranty Typically 1 year (region‑dependent)
Feature Details Chipset / Socket AMD X670 / AM5 CPU Support AMD Ryzen 7000 series (AM5 socket) Power Delivery 16+2+2 Twin Digital VRM Design (70A DrMOS) Memory Support DDR5 up to 6666MHz (OC), 4× DIMMs, Dual Channel PCIe Slots 1× PCIe 5.0 x16, 1× PCIe 4.0 x4 Storage Support 1× PCIe 5.0 M.2, 2× PCIe 4.0 M.2, 4× SATA III USB Ports USB 3.2 Gen 2×2 Type-C, Gen 2 Type-A/C, Gen 1 & 2.0 Wi‑Fi & Bluetooth Intel Wi‑Fi 6E + Bluetooth 5.2 Ethernet Realtek 2.5 GbE LAN Audio Realtek ALC1220 HD Audio codec BIOS Features Q-Flash Plus (BIOS update without CPU), Dual BIOS Form Factor ATX RGB & Software RGB Fusion 2.0, Smart Fan 6, EasyTune, APP Center
Gaming Z Pro
Steel
462x218x456 mm(LxWxH)
HDD Cage (Bottom): 3.5″ x1
HDD Cage (Top): 3.5″ & 2.5″ Combo x1
SSD Bracket: 2.5″ x2
7 Standard Slots
E-ATX, ATX, M-ATX, Mini-ITX
Standard PS2 ATX PSU
Top: 120mm x3 or 140mm x2
Front: 120mm x3
MB: 120mm x2 (E-ATX MB Width ≤ 28cm)
PSU Shroud: 120mm x3
Rear: 120mm x1
Top: 360
Front: 360 (Memory Height ≤ 45mm)
Rear: 120
USB3.0 x1, USB2.0 x2, HD Audio
170mm
285mm (Fan on MB Panel)
420mm (No Fan on MB Panel)
220mm
Feature Details Chipset / Socket AMD X870 / AM5 CPU Support Ryzen 7000 / 8000 / 9000 series VRM Design 16 + 2 + 1 phases (80 A SPS) Memory DDR5, up to DDR5‑AEMP Storage 4 x M.2 slots (2 × PCIe 5.0, 2 × PCIe 4.0), 2× SATA GPU Expansion PCIe 5.0 x16, PCIe 4.0 x16 (×4) Wireless / LAN Wi‑Fi 7 (2.9 Gbps), 2.5 Gb Ethernet USB Connectivity 2x USB4, 10 Gbps, 20 Gbps front C with PD, plus USB 5/2.0 Audio Codec Realtek ALC1220P with DTS Cooling Heatsinks, smart fan features, AI Cooling II DIY Features BIOS FlashBack, Q‑Latch, I/O shield etc. Software / AI Tools Asus AI suite, Armoury Crate, Aura Sync
Integrated Graphics Processor with AMD Radeon™ Graphics support:
– 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz
* Support for HDMI 2.1 version, HDCP 2.3, and HDR.
** Support for native HDMI 2.1 TMDS compatible ports.
– 2 x DisplayPorts, supporting a maximum resolution of 3840×2160@144 Hz
* Support for DisplayPort 1.4 version.
(Graphics specifications may vary depending on CPU support.)
Support for up to triple-display at the same time
Realtek® Audio CODEC
High Definition Audio
2/4/5.1/7.1-channel
* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x16 mode
AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode
AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode
* The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.
Chipset:
– 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x4 (PCIEX4)
1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2580/2280 SSDs:
AMD Ryzen™ 9000/7000 Series Processors support PCIe 5.0 x4/x2 SSDs
AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs
1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3, M key, type 22110/2280 SSDs:
AMD Ryzen™ 9000/7000 Series Processors support PCIe 4.0 x4/x2 SSDs
AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs
AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs
4 x SATA 6Gb/s connectors
RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices
* RAID 5 is only available on AMD Ryzen™ 9000 Series Processors.
RAID 0, RAID 1, and RAID 10 support for SATA storage devices
1 x HDMI port (Note)
2 x DisplayPorts (Note)
1 x PS/2 keyboard/mouse port
1 x Q-Flash Plus button
1 x USB Type-C® port, with USB 3.2 Gen 1 support
3 x USB 3.2 Gen 1 ports
2 x USB 2.0/1.1 ports
1 x RJ-45 port
3 x audio jacks
(Note) Actual support may vary by CPU.
Voltage detection
Temperature detection
Fan speed detection
Water cooling flow rate detection
Fan fail warning
Fan speed control
* Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.
Support for GIGABYTE Control Center (GCC)
* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
Support for Q-Flash
Support for Q-Flash Plus
Support for Smart Backup
Brand GIGABYTE Model X570 UD CPU Socket Type AM4 CPU Type AMD Socket AM4, support for: AMD Ryzen 5000 Series / 3rd Gen Ryzen/2nd Gen Ryzen / 3nd Gen Ryzen with Radeon Vega Graphics/2nd Gen Ryzen with Radeon Vega Graphics/Ryzen with Radeon Vega Graphics Processors
* Support for Ryzen 5000 Series with BIOS UPDATE. Refer to GIGABYTE website for CPU support list.Chipset AMD X570 Number of Memory Slots 4x288pin (DDR4) Memory Standard 3rd Generation AMD Ryzen processors:
Support for DDR4 4000(O.C.)/ 3866(O.C.)/ 3800(O.C.)/ 3733(O.C.)/ 3600(O.C.)/ 3466(O.C.)/ 3400(O.C.)/ 3333(O.C.)/ 3300(O.C.)/ 3200/ 2933/ 2667/ 2400/ 2133 MHz memory modules
2nd Generation AMD Ryzen processors / 2nd Generation AMD Ryzen with Radeon Vega Graphics processors / AMD Ryzen with Radeon Vega Graphics processors:
Support for DDR4 3200(O.C.)/ 2933/ 2667/ 2400/ 2133 MHz memory modulesMaximum Memory Supported 128GB Channel Supported Dual Channel PCI Express 4.0 x16 Integrated in the CPU (PCIEX16):
- 3rd Generation AMD Ryzen processors:
1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16
- 2nd Generation AMD Ryzen processors:
1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
- 2nd Generation AMD Ryzen with Radeon Vega Graphics processors / AMD Ryzen with Radeon Vega Graphics processors:
1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x8
Integrated in the Chipset (PCIEX4/PCIEX1)
2 x PCI Express x16 slots, supporting PCIe 4.0*/3.0 and running at x4 (PCIEX4)
* For 3rd Generation AMD Ryzen processors only.PCI Express x1 2 x PCI Express x1 slots, supporting PCIe 4.0*/3.0
* For 3rd Generation AMD Ryzen processors only.Serial ATA (SATA) 6 x SATA 6Gb/s M.2 Integrated in the CPU:
- 3rd Generation AMD Ryzen processors:
1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 4.0 x4/x2 SSD support)
- 2nd Generation AMD Ryzen processors / 2nd Generation AMD Ryzen with Radeon Vega Graphics processors / AMD Ryzen with Radeon Vega Graphics processors:
1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support)SATA RAID 0/1/10 Onboard Video Chipset Integrated Graphics Processor:
1 x HDMI port, supporting a maximum resolution of 4096x2160@60Hz
* Support for HDMI 2.0 version, HDCP 2.2, and HDR.
Maximum shared memory of 16GB
Note: For 2nd Generation AMD Ryzen with Radeon Vega Graphics processors / AMD Ryzen with Radeon Vega Graphics processors only.Audio Chipset Realtek ALC887 Audio Channels 2/4/5.1-channel LAN Chipset Realtek GbE LAN chip Max LAN Speed 1Gbps Back I/O Ports 1 x PS/2 keyboard/mouse port
1 x HDMI port
4 x USB 3.2 Gen 1 ports
2 x USB 2.0/1.1 ports
1 x Q-Flash Plus button
1 x RJ-45 port
3 x audio jacksOnboard USB 2 x USB 3.2 Gen 1 headers
2 x USB 2.0/1.1 headersOther Connectors 1 x CPU fan header
1 x water cooling CPU fan header
2 x system fan headers
1 x RGB LED strip header
1 x front panel header
1 x front panel audio header
1 x Trusted Platform Module (TPM) header (2x6-pin, for the GC-TPM2.0_S module only)
1 x Clear CMOS jumperForm Factor ATX LED Lighting RGB Dimensions (W x L) 12.0" x 9.6" Power Pin 1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connectorWindows 11 Supported
Brand GIGABYTE Model B850 GAMING WIFI6 CPU Socket Type AM5 CPU Type Ryzen 7000 Series / Ryzen 8000 Series / Ryzen 9000 Series Chipset AMD B850 Number of Memory Slots 4x288pin (DDR5) Memory Standard Up to DDR5 8200(O.C) Maximum Memory Supported 256GB PCI Express 5.0 x16 1 x PCI Express 5.0 x16 M.2 3 x M.2 Max LAN Speed 1Gbps Wireless LAN Wi-Fi 802.11 ax Bluetooth Yes Back I/O Ports 1 x DisplayPort / 1 x HDMI / 1 x USB 3.2 Gen 2 Type-C / 2 x USB 3.2 Gen 1 Type-A / 2 x USB 3.2 Gen 2 Type-A / 4 x USB 2.0/1.1 Form Factor ATX
