Component Specification Supported CPU Sockets Intel: LGA 115x / 1200 / 1700 / 1851 / 2011 / 2066 AMD: AM4 / AM5 Radiator Dimensions 403 × 120 × 27 mm Pump / Cold-plate Dimensions 187.2 × 95.8 × 102 mm Fans 3 × TL-UB36 ARGB 120 mm Fan Max Speed 2150 RPM ±10% Fan Airflow 69 CFM (max) Fan Static Pressure 2.87 mm H₂O (max) Fan Noise 27 dBA (max) Pump Max Speed 6400 RPM ±10% Pump Voltage 12 V DC Pump Connector 4-pin PWM Radiator Material Aluminum Display / Screen 6.86-inch IPS, 1280 × 480 resolution Fan Dimensions 120 × 120 × 25 mm (per fan) ARGB Connector 3-pin 5V ARGB Bearing Type (Fans) S-FDB V2 Bearing Warranty 6 Years
Component Specification Supported CPU Sockets Intel: LGA 115x / 1200 / 1700 / 1851 / 2011 / 2066 AMD: AM4 / AM5 Radiator Dimensions 403 × 120 × 27 mm Pump / Cold-plate Dimensions 187.2 × 95.8 × 102 mm Fans 3 × TL-UB36 ARGB 120 mm Fan Max Speed 2150 RPM ±10% Fan Airflow 69 CFM (max) Fan Static Pressure 2.87 mm H₂O (max) Fan Noise 27 dBA (max) Pump Max Speed 6400 RPM ±10% Pump Voltage 12 V DC Pump Connector 4-pin PWM Radiator Material Aluminum Display / Screen 6.86-inch IPS, 1280 × 480 resolution Fan Dimensions 120 × 120 × 25 mm (per fan) ARGB Connector 3-pin 5V ARGB Bearing Type (Fans) S-FDB V2 Bearing Warranty 6 Years
Category Specification Model Samsung Odyssey OLED G6 G60SF (LS27FG602) Screen Size 27-inch (flat panel) Panel Type QD-OLED Resolution QHD 2560 × 1440 Aspect Ratio 16:9 Active Display Area 590.42 × 333.72 mm Refresh Rate Up to 500 Hz Response Time 0.03 ms (GtG) Brightness (Typical / Min) 300 cd/m² (typical), 200 cd/m² (min) Peak Brightness (HDR) Up to 1000 nits Contrast Ratio 1,000,000:1 Color Gamut ~99% DCI-P3, 1.07B colors Viewing Angles 178° (H) / 178° (V) Surface Treatment Glare-free / Low-reflection Adaptive Sync NVIDIA G-Sync Compatible, AMD FreeSync Premium Pro HDR Support VESA DisplayHDR TrueBlack 500, HDR10+ Gaming Burn-In Protection OLED Safeguard+ (Dynamic Cooling, Thermal Modulation, Logo/Taskbar Detection, Screen Saver) Connectivity 2 × HDMI 2.1, 1 × DisplayPort 1.4, USB-B upstream, USB-A downstream, 3.5 mm headphone out Stand Adjustments Height, tilt, swivel, pivot Dimensions (W × H × D) With stand: ~611.7 × 554.2 × 263.5 mm; Without stand: ~611.7 × 353.8 × 49.2 mm Weight With stand: ~6.9 kg; Without stand: ~3.8 kg Power Consumption Max ~140 W Operating Conditions Temp: 0-40 °C; Humidity: 10-80% (non-condensing) Warranty 3 years (burn-in under normal use covered)
Feature Specification CPU & Chipset Intel LGA 1700 socket; supports 12th, 13th, and 14th Gen Intel Core, Pentium Gold, and Celeron processors; Intel Z790 chipset VRM & Power Design 16+1+1 phases digital VRM; 6-layer PCB with 2X copper; 8+8 phases parallel power design Memory (RAM) 4 × DDR5 DIMM slots (dual-channel); up to 128 GB; supports XMP 3.0 memory modules Storage 3 × PCIe 4.0 ×4 M.2 slots with Thermal Guard; 6 × SATA 6 Gb/s ports (RAID 0/1/5/10) Expansion Slots 1 × PCIe 5.0 ×16 slot (reinforced); 2 × PCIe 4.0 ×16 slots; 2 × PCIe 3.0 ×1 slots Networking 2.5 GbE LAN; no Wi-Fi Rear I/O Ports 2 × USB 2.0; 4 × USB 3.2 Gen 1; 1 × USB 3.2 Gen 2; 1 × USB 3.2 Gen 2x2 Type-C; 1 × HDMI 2.0; 1 × DisplayPort; 1 × RJ-45 LAN; 3 × audio jacks; 1 × S/PDIF; 1 × Q-Flash Plus button Internal Headers 1 × USB 3.2 Gen 1 Type-C; 2 × USB 3.2 Gen 1; 2 × USB 2.0; 1 × USB 3.2 Gen 2x2 Type-C; 1 × USB 3.2 Gen 2; 1 × RGB LED header; 1 × Addressable LED header; 1 × TPM header; 1 × Clear CMOS jumper Audio Realtek ALC897 codec; 7.1-channel HD audio; high-end audio capacitors; S/PDIF out Cooling & DIY Features Smart Fan 6; multiple temperature sensors; hybrid fan headers with FAN STOP; EZ-Latch PCIe 4.0 ×16 slot with quick release design; M.2 Thermal Guard Form Factor ATX (305 × 244 mm) Special Features Multi-key (configurable BIOS functions); Q-Flash Plus (BIOS update without CPU, memory, or graphics card); RGB Fusion (addressable and RGB LED headers)
Feature Specification CPU & Chipset AMD Socket AM5; supports Ryzen 7000 / 8000 / 9000 Series; AMD X870E chipset VRM & Power Design 16+2+2 Digital Twin VRM; 110A SPS power stages Memory (RAM) 4 × DDR5 DIMM slots (dual-channel); up to 256 GB; speeds up to DDR5-8600 OC; supports AMD EXPO & Intel XMP Storage 3 × M.2 slots (3 × PCIe 5.0 ×4); 4 × SATA 6 Gb/s (RAID 0/1/10) Expansion Slots 1 × PCIe 5.0 ×16 (reinforced PCIe UD Slot); additional PCIe 4.0/3.0 slots Networking 5 GbE LAN; Wi-Fi 7 with ultra-high gain antenna; Bluetooth 5.4 Rear I/O Ports 2 × USB4 Type-C (DP-Alt); 4 × USB 3.2 Gen2; 4 × USB 3.2 Gen1; 2 × USB 2.0; HDMI 2.1; S/PDIF; Q-Flash Plus button Internal Headers Front USB-C 20Gb/s; USB 3.2 Gen1/2 headers; USB 2.0 headers; RGB/ARGB headers; multiple fan/pump headers Audio Realtek ALC1220 codec; 8-channel HD audio; audiophile-grade capacitors; S/PDIF out Cooling & DIY Features VRM Thermal Armor; M.2 Thermal Guard; EZ-Latch Plus (PCIe & M.2 tool-less); EZ-Latch Click; EZ-Debug Zone; Smart Fan 6; Wi-Fi EZ-Plug Form Factor ATX (305 × 244 mm) Special Features AORUS AI SNATCH (one-click DDR5 performance boost); Q-Flash Plus; Windows 11 support
Feature Specification Chipset Intel B760 CPU Support Intel 12th, 13th, and 14th Gen Core, Pentium Gold, Celeron (LGA 1700 socket) Memory Support 4× DDR5 DIMM slots, up to 192GB, Dual Channel, up to 7600MT/s (OC) Expansion Slots 1× PCIe 4.0 x16, 1× PCIe 3.0 x16 (x4), 1× PCIe 3.0 x1 Storage 2× M.2 (PCIe 4.0 x4 / PCIe 3.0 x4), 4× SATA 6Gb/s Graphics Outputs 1× HDMI 2.1, 1× DisplayPort 1.2, 1× D-Sub Audio Realtek 8-Channel HD Audio Networking Realtek 2.5GbE LAN USB Ports (Rear) 1× USB-C 3.2 Gen2, 2× USB-A 3.2 Gen2, 4× USB-A 2.0 USB Ports (Internal) Supports front-panel USB-C 3.2 Gen1, USB-A 3.2 Gen1, USB 2.0 Form Factor ATX Power Phase Design 6+2+1 VRM Other Features Q-Flash, Smart Fan 6, PCIe EZ-Latch
Category Details Chipset AMD X870 CPU Support AMD Ryzen 9000 Series (Zen 5) & Ryzen 7000 (AM5) Socket AM5 Form Factor ATX Memory Support 4× DDR5 DIMM, up to 192GB, up to 8000+ MT/s (OC), Dual Channel, AMD EXPO & Intel XMP PCIe Slots 1× PCIe 5.0 x16 (GPU), 1× PCIe 4.0 x16 (x4), 2× PCIe 4.0 x1 M.2 Slots 1× PCIe 5.0 x4, 3× PCIe 4.0 x4 SATA Ports 4× SATA 6Gb/s Networking (LAN) Intel 2.5Gb Ethernet Wireless WiFi 7, Bluetooth 5.4 USB Ports (Rear I/O) 1× USB 3.2 Gen 2x2 (20Gbps Type-C), 2× USB 3.2 Gen 2 (10Gbps), 4× USB 3.2 Gen 1, 4× USB 2.0 Audio ROG SupremeFX 7.1 HD Audio Codec ALC4080, DTS Sound Unbound Power Stages 16+2 Power Stages, ProCool II connectors, Alloy Chokes, Durable Capacitors Cooling Features Large VRM heatsinks, multiple fan headers, hybrid fan control, M.2 heatsinks RGB ASUS Aura Sync RGB Lighting, RGB & ARGB headers Expansion Q-Release PCIe Slot, Q-Latch for M.2 Dimensions ATX – 30.5 cm × 24.4 cm
Power Supply Position Case Bottom Cooler Fan cooler fan’s price not included Cooler Fan Support M/B Side 3*120mm Top 3*120mm Rear 1*120mm Bottom3*120mm USB I/O 3.0*1+ 1.0*2+HD.AUDIO HDD/SSD HDD*1+SSD*3 Motherboard Support ATX/Micro-ATX Material & Thickness 0.50mm SPCC/SGCC Size without front panel and legs（L*W*H) 416X278X413MM Size with front panel and legs（L*W*H) 420X278X430MM Package size（L*W*H) 498X345X488MM Net Weight 5.0KG Gross Weight 5.8KG PCI Slots 7 slots VGA length limit 410mm CPU height limit 158mm MOQ 1200/40HQ
Power Supply Position Case Bottom Cooler Fan cooler fan’s price not included Cooler Fan Support M/B Side 3*120mm Top 3*120mm Rear 1*120mm Bottom3*120mm USB I/O 3.0*1+ 1.0*2+HD.AUDIO HDD/SSD HDD*1+SSD*3 Motherboard Support ATX/Micro-ATX Material & Thickness 0.50mm SPCC/SGCC Size without front panel and legs（L*W*H) 416X278X413MM Size with front panel and legs（L*W*H) 420X278X430MM Package size（L*W*H) 498X345X488MM Net Weight 5.0KG Gross Weight 5.8KG PCI Slots 7 slots VGA length limit 410mm CPU height limit 158mm MOQ 1200/40HQ
